MACROLEX® Green 5B Gran

Principal: LANXESS CAB

Color (Properties): Green

Functions: Dye

Compatible Polymers & Resins: Acrylonitrile Butadiene Styrene (ABS), PC/ABS Alloy, Poly(Methyl Methacrylate) (PMMA), Polycarbonates (PC), Polyethylene Terephthalate (PET), Polystyrenes (PS), Styrene Acrylonitrile (SAN), Unplasticised Polyvinyl Chloride (PVC-U)

    Enhanced TDS

    Identification & Functionality

    Chemical Family
    Anthraquinones
    Function
    Dye
    Plastics & Elastomers Functions
    Dye
    Product Code
    MITM14419
    Technologies
    Plastics
    Product Families
    Plastics — Polymer Additives
    Pigments & Colorants

    Features & Benefits

    Labeling Claims
    Not Listed In California Proposition 65
    Materials Features
    Reduced Dusting

    Applications & Uses

    Applicable Processes
    Transparent Dyeing,
    Opaque Dyeing
    Compatible Polymers & Resins
    PC/ABS Alloy,
    Acrylonitrile Butadiene Styrene (ABS),
    Poly(Methyl Methacrylate) (PMMA),
    Polyethylene Terephthalate (PET),
    Polycarbonates (PC),
    Styrene Acrylonitrile (SAN),
    Unplasticised Polyvinyl Chloride (PVC-U),
    Polystyrenes (PS)
    Plastics & Elastomers End Uses
    Toys,
    Household Goods
    Product Applications
    • Transparent and opaque dyeing of PS, SAN, PMMA, PC, PET, ABS and ABS / PC blends.

    Properties

    Color (Properties)
    Green
    Physical Form
    Microgranule
    Notes

    * For Styrene-butadiene block copolymer the use of this dye is not recommended.

    Regulatory & Compliance

    Certifications & Compliance
    BfR Recommendation

    Technical Details & Test Data

    Technical Data

    Fastness to bleeding:

    • Suitability for dyeing household utensils
    • No staining of distilled water, 2% by weight acetic acid, 10% by volume ethanol, coconut oil or peanut oil in our test on 0.1% dyeing of PS, ABS, SAN, PMMA, PC, PET and PVC-U.
    • The tests were carried out in accordance with the recommendations of the German BfR [for plastic applications (saturated strips of filter paper, 5h at 50°C)].

    Purity:

    • This dyestuff meets current purity requirements for dyeing household utensils and toys in Europe.

    Packaging & Availability

    Packaging Type
    Bags

    Other

    Appearance
    Green with a blue cast low dusting microgranulate
    Appearance (SDS)
    Microgranules
    Bulk Density
    0.45 g/cm³
    Bulk Density (SDS)
    170.0 kg/m³
    Color (SDS)
    Green
    Density
    1.35 g/cm³
    Density (SDS)
    1.35 g/cm³
    Dye Content
    0.105 %
    Dye Content
    0.105 %
    Dye Content
    0.2 %
    Dye Content
    0.105 %
    Dye Content
    0.105 %
    Dye Content
    0.2 %
    Item Number
    ITM22716
    Light Fastness
    7.0-8.0
    Light Fastness
    7.0-8.0
    Light Fastness
    6.0
    Light Fastness
    6.0
    Light Fastness
    5.0-6.0
    Light Fastness
    7.0-8.0
    Light Fastness
    7.0-8.0
    Light Fastness
    7.0-8.0
    Light Fastness
    6.0
    Light Fastness
    6.0
    Light Fastness
    5.0-6.0
    Light Fastness
    7.0-8.0
    Melting Point
    213.0 °C
    Melting Point (SDS)
    437.0 °F
    Odor (SDS)
    Odorless
    Other Hazards
    None known.
    Principal
    LANXESS CAB
    Shelf Life
    60.0 mo
    Solubility In Water (SDS)
    0.0014 mg/L
    Solubility in Acetone
    1.0 g/L
    Solubility in Butyl Acetate
    3.0 g/L
    Solubility in Ethanol
    0.1 g/L
    Thermal Resistance
    280.0 °C
    Thermal Resistance
    260.0 °C
    Thermal Resistance
    280.0 °C
    Thermal Resistance
    350.0 °C
    Thermal Resistance
    290.0 °C
    Thermal Resistance
    300.0 °C
    Thermal Resistance
    280.0 °C
    Thermal Resistance
    300.0 °C
    Thermal Resistance
    300.0 °C
    Thermal Resistance
    280.0 °C
    Thermal Properties
    ValueUnitsTest Method / Conditions
    Thermal Resistance280.0 °C°CDIN EN 12877 at 1/3 Standard depth, with 1% titanium dioxide, PA 6
    Thermal Resistance260.0 °C°CDIN EN 12877 at 1/3 Standard depth, with 1% titanium dioxide, PA 6.6
    Thermal Resistance280.0 °C°CDIN EN 12877 at 1/3 Standard depth, with 1% titanium dioxide, PBT
    Thermal Resistance350.0 °C°CDIN EN 12877 at 1/3 Standard depth, with 1% titanium dioxide, PC
    Thermal Resistance290.0 °C°CDIN EN 12877 at 1/3 Standard depth, with 1% titanium dioxide, PET
    Thermal Resistance300.0 °C°CDIN EN 12877 at 1/3 Standard depth, with 1% titanium dioxide, PMMA
    Thermal Resistance280.0 °C°CDIN EN 12877 at 1/3 Standard depth, with 1% titanium dioxide, SAN
    Thermal Resistance300.0 °C°CDIN EN 12877 at 1/3 Standard depth, with 1% titanium dioxide, SB
    Thermal Resistance300.0 °C°CDIN EN 12877 at 1/3 Standard depth, with 2% titanium dioxide, PS
    Thermal Resistance280.0 °C°CDIN EN 12877 at 1/3 Standard depth, with 4% titanium dioxide, ABS
    Chemical Properties
    ValueUnitsTest Method / Conditions
    Dye Content0.105 %%Blue Wool Scale (BWS) at 1/3 standard depth with 1% titanium dioxide (PS 2% titanium dioxide), transparent coloration with 0.05% dye, PMMA
    Dye Content0.105 %%Blue Wool Scale (BWS) PC, 1/3 standard depth with 1% titanium dioxide (PS 2% titanium dioxide), transparent coloration with 0.05% dye
    Dye Content0.2 %%Blue Wool Scale (BWS) PS, at 1/3 standard depth with 1% titanium dioxide (PS 2% titanium dioxide), transparent coloration with 0.05% dye
    Dye Content0.105 %%DIN EN ISO 4892-2 at 1/3 standard depth with 1% titanium dioxide (PS 2% titanium dioxide), transparent coloration with 0.05% dye, PMMA
    Dye Content0.105 %%DIN EN ISO 4892-2 PC, 1/3 standard depth with 1% titanium dioxide (PS 2% titanium dioxide), transparent coloration with 0.05% dye
    Dye Content0.2 %%DIN EN ISO 4892-2 PS, at 1/3 standard depth with 1% titanium dioxide (PS 2% titanium dioxide), transparent coloration with 0.05% dye
    Shelf Life & Stability
    ValueUnitsTest Method / Conditions
    Light Fastness7.0-8.0-Blue Wool Scale (BWS) at 1/3 Standard depth, dye content 0.105%, PC, Transparent
    Light Fastness7.0-8.0-Blue Wool Scale (BWS) at 1/3 Standard depth, dye content 0.105%, PMMA, Transparent
    Light Fastness6.0-Blue Wool Scale (BWS) at 1/3 Standard depth, dye content 0.105%, with 1% titanium dioxide, PC, Reduction
    Light Fastness6.0-Blue Wool Scale (BWS) at 1/3 Standard depth, dye content 0.105%, with 1% titanium dioxide, PMMA, Reduction
    Light Fastness5.0-6.0-Blue Wool Scale (BWS) at 1/3 Standard depth, dye content 0.2%, with 2% titanium dioxide, PS, Reduction
    Light Fastness7.0-8.0-Blue Wool Scale (BWS) at 1/3 Standard depth, dye content 0.3%, PS, Transparent
    Light Fastness7.0-8.0-DIN EN ISO 4892-2 at 1/3 Standard depth, dye content 0.105%, PC, Transparent
    Light Fastness7.0-8.0-DIN EN ISO 4892-2 at 1/3 Standard depth, dye content 0.105%, PMMA, Transparent
    Light Fastness6.0-DIN EN ISO 4892-2 at 1/3 Standard depth, dye content 0.105%, with 1% titanium dioxide, PC, Reduction
    Light Fastness6.0-DIN EN ISO 4892-2 at 1/3 Standard depth, dye content 0.105%, with 1% titanium dioxide, PMMA, Reduction
    Light Fastness5.0-6.0-DIN EN ISO 4892-2 at 1/3 Standard depth, dye content 0.2%, with 2% titanium dioxide, PS, Reduction
    Light Fastness7.0-8.0-DIN EN ISO 4892-2 at 1/3 Standard depth, dye content 0.3%, PS, Transparent
    Shelf Life60.0 momo
    Physical Properties
    ValueUnitsTest Method / Conditions
    Bulk Density0.45 g/cm³g/cm³DIN EN ISO 787-11
    Density1.35 g/cm³g/cm³at 23°C
    Melting Point213.0 °C°C
    Solubility in Acetone1.0 g/Lg/Lat 23°C
    Solubility in Butyl Acetate3.0 g/Lg/Lat 23°C
    Solubility in Ethanol0.1 g/Lg/Lat 23°C
    SDS Physical and Chemical Properties
    ValueUnitsTest Method / Conditions
    Bulk Density (SDS)170.0 kg/m³kg/m³
    Density (SDS)1.35 g/cm³g/cm³at 20°C
    Melting Point (SDS)437.0 °F°F
    Solubility In Water (SDS)0.0014 mg/Lmg/LRegulation (EC) No. 440/2008, Annex, A.6 at 20⁰C
