Enhanced TDS
Identification & Functionality
- Base Chemicals Functions
- Blend
- No
- Chemical Family
- Chemical Name
- Plastics & Elastomers Functions
- Product Code
- MITM12187
- Single Ingredient
- Yes
- Synonyms
- Elbor
- Technologies
- Product Families
Features & Benefits
- Base Chemicals Features
- Labeling Claims
- Materials Features
Applications & Uses
Properties
- Physical Form
Technical Details & Test Data
- Test Data
3M™ Boron Nitride Cooling Fillers 003SF 001 and 003SF Preferred for thin films <25 μm and fibers, fine channels and windings. 3M™ Boron Nitride Cooling Fillers 003SF has a controlled top size.
Principal Information
- Group Principal Number
- S002409
- Principal
Other
- Color (SDS)
- White
- Odor (SDS)
- Odorless
- Protect from Freezing
- No
- Temperature Control
- No
- USA/DOT UN Number
- Not Applicable
- Chemical Properties
Value Units Test Method / Conditions Active Oxygen Content min. 0.7 % % - Material Composition
Value Units Test Method / Conditions Boric Oxide Content min. 0.2 % % Boron Nitride Content max. 98.0 % % Carbon Content min. 0.2 % % - Physical Properties
Value Units Test Method / Conditions Bulk Density max. 0.15 g/cm³ g/cm³ Particle Size 0.5-2.0 µm µm D(0.1) Particle Size 2.0-6.0 µm µm D(0.5) Particle Size 6.0-14.0 µm µm d(0.9) Specific Surface Area max. 20.0 m²/g m²/g - SDS Physical and Chemical Properties
Value Units Test Method / Conditions Bulk Density (SDS) 50.0-550.0 kg/m³ kg/m³ Decomposition Temperature (SDS) 2730.0 °C °C Density (SDS) 2.25 g/cm³ g/cm³ at 20ºC Solubility In Water (SDS) max. 0.000162 g/L g/L At 20°C Solubility In Water (SDS) max. 0.162 mg/L mg/L UN Test Method
