Enhanced TDS
Identification & Functionality
- Base Chemicals Functions
- Blend
- No
- CASE Ingredients Functions
- Chemical Family
- Chemical Name
- Country of Origin
- Fluids & Lubricants Functions
- Function
- Filler, Intermediate
- Plastics & Elastomers Functions
- Product Code
- MITM12970
- Single Ingredient
- Yes
- Synonyms
- Elbor
- Technologies
- Product Families
Features & Benefits
- CASE Ingredients Features
- Fluids & Lubricants Features
- Labeling Claims
- Materials Features
- Product Features
- Increases thermal conductivity while maintaining electrical insulation.
- Compatible with standard polymers.
- Low density.
Applications & Uses
- Fluids & Lubricants End Use
- Fluids & Lubricants Type
- Plastics & Elastomers End Uses
- Plastics & Elastomers Processing Methods
- Markets
- Applications
- Processing Information
Factors such as melt temperature, compounding technique, injection rate and more can have a significant effect on the thermal and electrical insulative properties of parts made with boron nitride cooling fillers.
Properties
- Physical Form
Regulatory & Compliance
- Quality Standards
Technical Details & Test Data
- Technical Data
Ideal for thin films <50 μm due to its controlled top size. Highest reflectivity and increased in-plane thermal conductivity in pads.
Packaging & Availability
- Packaging Type
Principal Information
- Group Principal Number
- S002409
- Principal
Other
- Color (SDS)
- White
- Item Number
- Odor (SDS)
- Odorless
- Other Hazards
- May cause thermal burns
- Temperature Control
- No
- USA/DOT UN Number
- Not Applicable
- Chemical Properties
Value Units Test Method / Conditions Active Oxygen Content max. 0.5 % % - Material Composition
Value Units Test Method / Conditions Boron Nitride Content min. 98.5 % % Boron Trioxide Content max. 0.1 % % Carbon Content max. 0.06 % % - Physical Properties
Value Units Test Method / Conditions Bulk Density max. 0.22 g/cm³ g/cm³ ASTM B329 Bulk Density max. 0.22 g/cm³ g/cm³ ISO 3923-2 Bulk Density max. 0.22 g/cm³ g/cm³ Scott Volumeter Particle Size 5.0-8.0 µm µm Laser Light Scattering 0.1 bar, d(0.5), mastersizer 2000, dry Particle Size 10.0-20.0 µm µm Laser Light Scattering 0.1 bar, d(0.9), mastersizer 2000, dry Particle Size 1.5-3.0 µm µm Laser Light Scattering d(0.1), mastersizer 2000, dispersion in ethanol Particle Size 1.5-3.0 µm µm Laser Light Scattering d 0.1, mastersizer 2000, dry, 0.1 bar Particle Size 5.0-8.0 µm µm Laser Light Scattering D(0.5) Particle Size 10.0-20.0 µm µm Laser Light Scattering D90 Specific Surface Area max. 13.0 m²/g m²/g - SDS Physical and Chemical Properties
Value Units Test Method / Conditions Bulk Density (SDS) 50.0-550.0 kg/m³ kg/m³ Decomposition Temperature (SDS) 2730.0 °C °C Density (SDS) 2.25 g/cm³ g/cm³ at 20°C Solubility In Water (SDS) max. 0.162 mg/L mg/L - Shelf Life & Stability
Value Units Test Method / Conditions Shelf Life 0.0 d d
